Re: [STDS-802-11-TGBE] [EXT] RE: [STDS-802-11-TGBE] PDT-PHY-Mathematical description of signals



Hi Ron,



  Thanks for reviewing the draft.

  1. I can highlight the power deboosting factor for EHT TB PPDU for now.
  2.  is used in on page 7,                 (34-3.9-12)
  3. I will fix the tone index.



Thanks

Yan



From: Ron Porat <ron.porat@xxxxxxxxxxxx>
Sent: Wednesday, September 9, 2020 7:22 PM
To: Yan(msi) Zhang <yan.zhang_5@xxxxxxx>; STDS-802-11-TGBE@xxxxxxxxxxxxxxxxx
Subject: [EXT] RE: [STDS-802-11-TGBE] PDT-PHY-Mathematical description of signals



Hi Yan,



A few more comments:



Subclause

Page No.

Comment

34.3.9.3

6

power deboosting of preamble ([1/sqrt(2), 1] scaling factor) is copied from 11ax. Perhaps highlighted in yellow for now?

34.3.9.3

8

Omega_20MHz and its cardinality defined but not used in this section, preferable to be defined when used (for punctured preamble fields)

34.3.9.3

9

Gamma definition for 320 MHz (eq. 34-3.9-13) uses HE/EHT tone indices (up to 4096 tones for 320 MHz), since this applies to pre-EHT fields its should use legacy tone indices (1024 tones per 320 MHz BW)?



Thanks,

Ron







From: Yan(msi) Zhang [mailto:yan.zhang_5@xxxxxxx]
Sent: Wednesday, September 02, 2020 9:01 AM
To: STDS-802-11-TGBE@xxxxxxxxxxxxxxxxx
Subject: [STDS-802-11-TGBE] PDT-PHY-Mathematical description of signals



Hi Sigurd, Tianyu, Alfred,



Could you please add DCN 1337r2 to the PHY agenda? The link is  https://mentor.ieee.org/802.11/dcn/20/11-20-1337-01-00be-pdt-phy-mathematical-description-of-signals.docx.



Thanks

Yan
