Re: [STDS-802-11-TGBE] Typos in D0.2



Hi Tianyu, Alice,

I am sorry for my late reply.

The unintentional copy-and-paste error in the equation is fixed.   I have also replaced the duplicated "320 MHz-1" with "320 MHz-2" in Tables 36-19, 36-21, and 36-22.

Regards,
Edward

On Tue, Dec 22, 2020 at 2:51 AM Alice Jialing Li <jialing.li.phd2@xxxxxxxxx> wrote:
Hi Tianyu,

Thanks for pointing out the typos in the U-SIG section. Sameer and I will fix this in the next update of this section to D0.3.

Thanks,
Alice Chen
Qualcomm


On Mon, Dec 21, 2020 at 2:15 PM Tianyu Wu <0000109ac93c8e11-dmarc-request@xxxxxxxxxxxxxxxxx> wrote:
Hi Edward,

A few typos in 11be D0.2.

1. D0.2 PP244, ln 15, Equation 36-36. The last 0_23 highlighted in red circle is redundant. Note that this is correct in original SFD (1262r21 pp55).

SFD pp55:

The 4× 320 MHz EHT-LTF sequences are given as follows.

LTF320M_4x =

[ C(1)×LTF80M_4x_left, zeros(1,5), C(2)×LTF80M_4x_right, zeros(1,23), ...

  C(3)×LTF80M_4x_left, zeros(1,5), C(4)×LTF80M_4x_right, zeros(1,23), ...

  C(5)×LTF80M_4x_left, zeros(1,5), C(6)×LTF80M_4x_right, zeros(1,23), ...

  C(7)×LTF80M_4x_left, zeros(1,5), C(8)×LTF80M_4x_right ];


2. D0.2 pp205, The BW field of the U-SIG, Set to 5 should be change to 320 MHz-2.


Same for D0.2, pp210.

Thanks.
Tianyu
