Hi Alfred,
Please help to add the following to the motion list:
- Move to add the following text to Section 38.3.19.2 (Pre-correction accuracy requirements) of the PDT 11-24/1981r3, and also reflect the changes in D0.1?
For the ELR PPDU carrying immediate response frame in response to a preceding soliciting frame, after compensation, the absolute value of residual CFO error with respect to the preceding PPDU carrying soliciting frame shall
not exceed 15 kHz at the 10% point of the complementary cumulative distribution function (CCDF) of CFO error in AWGN at a received power of -82 dBm in the primary 20 MHz channel.
Reference document: [11-24/1841r1]. SP results: no objection
- Move to replace the TBD to 8us for the PE block in the Figure 38-xx (UHR ELR PPDU format) in Section 38.3.6 (UHR PPDU formats) in the PDT 11-24/1981r3, and also reflect the changes in D0.1?
- Note: the PE value applies for UHR ELR PPDU.
Reference document: [11-24/1841r1]. SP results: no objection
Thanks,
Rui
From: Alice Jialing Li Chen <jialing.li.phd2@xxxxxxxxx>
Sent: Sunday, January 12, 2025 10:43 PM
To: STDS-802-11-TGBN@xxxxxxxxxxxxxxxxx
Subject: [EXT] Re: [STDS-802-11-TGBN] Motions
|
Caution: This is an external email. Please take care when clicking links or opening attachments. When in doubt, report the message using the 'Report this email' button
|
Hi Alfred,
Please add the following to the motion list. It corresponds to the SP in slide 49 in the agenda document 11-24/2074r4, with a modification of adding the last sub-bullet per discussion.
Do you agree to add the following to the 11bn SFD?
-
CoBF is only applied in DL non-OFDMA MU MIMO transmission
-
C-SR is only applied in UHR DL SU transmission in each BSS
-
The entire U-SIG format in a UHR MU PPDU is as in the following figure
-
The definition of BSS color 1/2 are TBD
Supporting documents: [24/1834r4, 24/1831r3, 24/1864r1]
Result: 55Y/8N/22A
Regards,
Alice Chen
Qualcomm
From: Alfred Asterjadhi <asterjadhi@xxxxxxxxx>
Sent: Sunday, January 12, 2025 2:00 AM
To: STDS-802-11-TGBN@xxxxxxxxxxxxxxxxx
Subject: [STDS-802-11-TGBN] Updated TGbn Agenda Posted
Hello all,
I posted an updated version of the agenda (here).
It contains the most up to data queues and the allocations for the week. Please review and let me know if I have missed anything.
PS: I have yet to populate the SPs with the usual format for PHY/MAC/Joint. I expect to do so for the next revision of the agenda.
Regards,
Alfred
--
Alfred Asterjadhi, PhD
IEEE802.11 TGbe/TGbn Chair,
Qualcomm Technologies Inc.
Cell #: +1 858 263 9445
Office #: +1 858 658 5302
