Re: [STDS-802-11-TGM] Updated TGmd Teleconference agenda posted

--- This message came from the IEEE 802.11 Task Group M Technical Reflector ---
Adding the reflector.

I posted https://mentor.ieee.org/802.11/dcn/20/11-20-0145-07-000m-sb1-revmd-phy-sec-comments.xlsx

Updating CID 4326 to:
REVISED (PHY: 2020-03-09 20:44:00Z) - Incorporate the changes shown in https://mentor.ieee.org/802.11/dcn/20/11-20-0246-04-000m-d30crs.docx  for CID 4326, which removes the MA-UNITDATA discussion from the NOTE.

Update the resolution documented in the document above with this change:
at p2640.41, change the NOTE 2 to the following:

"NOTE 2 - Null and QoS (+)Null frames are not protected."

Updating CID 4388 to:
REVISED (PHY: 2020-03-09 19:53:01Z) - Add the following at 12.5.5.1 (GCMP Overview) P2614.62: “An S1G STA shall use PV0 frames when using GCMP encapsulation.”

There is no dependency of cryptographic encapsulation mechanisms on the 802.11 PHY.

Dorothy, please update the motion to PHY Motion C tab of 11-20/145r7.

Thanks,

Mike

On Thu, Mar 19, 2020 at 6:10 PM M Montemurro <montemurro.michael@xxxxxxxxx> wrote:
Bring this up on the call.

Cheers,

Mike

On Thu, Mar 19, 2020 at 6:04 PM Mark Rison <m.rison@xxxxxxxxxxx> wrote:

Hello Mike,

> Motion 170: PHY CIDs

a.       Approve comment resolutions included in the “PHY Motion C” tab  in https://mentor.ieee.org/802.11/dcn/20/11-20-0145-06-000m-sb1-revmd-phy-sec-comments.xlsx

Per the below and attached, I would like to request a change to the resolution

to CID 4326, from:



Change cited sentence at p2640.41 as follows



NOTE 2—Because the IEEE 802.11 Null frames are does not derive from an MA-UNITDATA.request primitive, it is not protected.



to



Change cited sentence at p2640.41 as follows



NOTE 2—Because the IEEE 802.11 Null and QoS (+)Null frames are does not derive from an MA-UNITDATA.request primitive, it is not protected.



Also, the resolution shown for CID 4388 is completely broken and needs

to be pulled or fixed:



REVISED (PHY: 2020-03-09 19:53:01Z) - Add the following at 12.5.5.1 (GCMP Overview) P2614.62: “An S1G .STA shall use PV0 frames when using GCMP encapsulation. There is no requirement that an S1G STA refrains from using ”



Thanks,



Mark



--

Mark RISON, Standards Architect, WLAN   English/Esperanto/Français

Samsung Cambridge Solution Centre       Tel: +44 1223  434600

Innovation Park, Cambridge CB4 0DS      Fax: +44 1223  434601

ROYAUME UNI                             WWW: http://www.samsung.com/uk



From: Mark Rison
Sent: 18 March 2020 15:40
To: 'Nehru Bhandaru' <nehru.bhandaru@xxxxxxxxxxxx>
Cc: 'rojan.chitrakar@xxxxxxxxxxxxxxxx' <rojan.chitrakar@xxxxxxxxxxxxxxxx>; Dorothy Stanley <dstanley1389@xxxxxxxxx> (dstanley1389@xxxxxxxxx) <dstanley1389@xxxxxxxxx>; Jouni Malinen (jouni@xxxxxxxxxxxxxxxx) <jouni@xxxxxxxxxxxxxxxx>
Subject: RE: [STDS-802-11-TGM] Updated TGmd Teleconference agenda posted



Hello Nehru,



Thanks for the update.  I attach my comments.



Note that Rojan has proposed some resolutions to 4088-4091 and 4093

in 20/0407.



Also, for 4087 I have drafted a resolution, namely:



Change "MIC" to "Encrypted MIC"

in Figure 12-23—CCMP decapsulation block diagram (also "Data" -> "Encrypted data" on the left),

Figure 12-29—GCMP decapsulation block diagram (also "Data" -> "Encrypted data" on the left),

Figure 12-18—CCMP encapsulation block diagram (also "Data" -> "Plaintext data" on the left and "Data" -> "data" on the right),

Figure 12-27—GCMP encapsulation block diagram (also "Data" -> "Plaintext data" on the left and "Data" -> "data" on the right),

and at 2608.51½, 2609.9½, 2618.29½.



Lowercase "Nonce" in Figure 12-18—CCMP encapsulation block diagram,

"Nonce" and "Header" in Figure 12-27—GCMP encapsulation block diagram,

"Nonce" in Figure 12-23—CCMP decapsulation block diagram,

"Nonce" and "Header" in Figure 12-29—GCMP decapsulation block diagram,

and ask the Editors to sharpen up Figure 12-23—CCMP decapsulation block diagram.



Thanks,



Mark



--

Mark RISON, Standards Architect, WLAN   English/Esperanto/Français

Samsung Cambridge Solution Centre       Tel: +44 1223  434600

Innovation Park, Cambridge CB4 0DS      Fax: +44 1223  434601

ROYAUME UNI                             WWW: http://www.samsung.com/uk



From: ***** 802.11 REVm - Revision Maintainance List ***** <STDS-802-11-TGM@xxxxxxxxxxxxxxxxx> On Behalf Of Nehru Bhandaru
Sent: 17 March 2020 21:15
To: STDS-802-11-TGM@xxxxxxxxxxxxxxxxx
Subject: Re: [STDS-802-11-TGM] Updated TGmd Teleconference agenda posted



--- This message came from the IEEE 802.11 Task Group M Technical Reflector ---

Hi Mike,



I uploaded 11-20-0246r5 based on our discussion on r4 in 11md tele conf/ad hoc. Could you please schedule some time for it during an upcoming 11md tele conf?



Thanks,



- N



On Wed, Mar 11, 2020 at 8:54 AM M Montemurro <montemurro.michael@xxxxxxxxx> wrote:

--- This message came from the IEEE 802.11 Task Group M Technical Reflector ---

Hi all,


I posted an updated teleconference agenda that includes the additional teleconferences that were announced earlier in the week.





Cheers,



Mike
