Re: [STDS-802-11-TGBN] TGbn Motion Request

Hi Alfred,

Can you please add the following to TGbn motions list (MAC PDT)? The SP passed with unanimous support on this PDT in Wednesday PM2 session.

“Move to incorporate the proposed text changes in 11-24/2056r1 to the latest TGbn draft (TGbn D0.1)"

Reference docs:[11-24/2056r1]. SP result: No objection


Thanks.

On Jan 14, 2025, at 7:22 PM, Cariou, Laurent <laurent.cariou@xxxxxxxxx> wrote:

Hi Alfred,
Please queue the following SP to the MAC:

Do you agree to add to the 11bn SFD:
  • For the following features, if an AP supports the feature, then it shall accept a request from an associated STA to enable or disable the feature on its (STA) side
    • Dynamic unavailability operation
    • Dynamic power save

Thanks,
Laurent


From: Jay Yang <yang.zhijie@xxxxxxxxxx>
Sent: Wednesday, January 15, 2025 11:53 AM
To: STDS-802-11-TGBN@xxxxxxxxxxxxxxxxx
Subject: Re: [STDS-802-11-TGBN] TGbn Motion Request


Hi Alfred,



Could help add the following motion to the agenda?



Move to include the following to the 11bn SFD?

As a part of M-AP coordination agreement procedure, an AP may assign an AP ID to another AP with the following constraints:

  • The AP ID is used for the AP to identify another AP as a coordinated AP, when necessary.
  • The AP ID field has the same size and the field value has a range as defined in AID field (see 9.4.1.8)
  • The AP shall ensure that the AP ID value is not assigned by the AP or by its affiliated MLD to any other STA (e.g., STA is an associated non-AP STA, an unassociated non-AP STA that has been allocated a RSID , or any other coordinated AP), or a non-AP MLD that is associated with the AP MLD
  • It's TBD whether the AP ID value is greater than 2^n where n is the maximum of the value carried in the MBSSID Indicator (n) field of the Multiple BSSID element for any AP affiliated with the AP MLD that belongs to a multiple BSSID set



No objection

Supporting list: 11-23/1837r2,11-24/1389r0, 11-24/1217r2,  11-24/0842r0,11-24/0843r0, 11-24/1016r2,11-24/1017r0, 11-23/1895r2, 11-24/0423r0,11-24/1225r0, 24/1220r0,25/0007r2






Thanks

Best Regards

Jay Yang (杨志杰)


Original
Date: 2025年01月15日 10:25
Subject: [STDS-802-11-TGBN] TGbn Motion Request
Hi Alfred,

Please add the following motion to the agenda:

Move to include the following to the 11bn SFD?

·         When the initiating AP requests the responding AP to join the CoBF sounding, the red subfields in the first and second User Info fields of the NDPA shall be set as follows.

·         NDPA Version Identifier is set to 0 for CoBF sounding in UHR

·         Number of LTF symbols is set to 0 and 1 for 4 and 8 symbols, respectively

·         Starting Spatial Stream is set to 0 and 1 for the 1st and 5th streams, respectively

·         Number of spatial streams is set to 0 and 1 for the 4 and 8 streams, respectively

·         LTF+GI is set to 0 and 1 for 2x LTF+0.8us GI and 2x LTF+1.6us GI, respectively

  • B20-26, which are shown as Reserved in the second User Info field, can be used in the future






                 Supporting doc: 11-24/1822r4, 11-24/1835r3, 11-24/1865r3


                 SP result: Passed with no objections.

Thanks,
Sameer
