Hi Alfred,

Please help add the following to the TGbn PHY motion list:

Motion 1: Move to include the following text to the 11bn SFD (DCN# 11-24/1590r1):

ELR LDPC rate matching will reuse the existing 802.11ac LDPC rate matching with 1-bit LDPC extra OFDM symbol indication

Result: no objection

Motion 2: Move to include the following text to the 11bn SFD (DCN# 11-24/1590r1):

ELR-SIG will use the following two OFDM symbols design

Result: no objection

Thanks,

Juan

From: Lin Yang <00002bbbd565f56a-dmarc-request@xxxxxxxxxxxxxxxxx>
Sent: Tuesday, November 12, 2024 9:05 PM
To: STDS-802-11-TGBN@xxxxxxxxxxxxxxxxx
Subject: Re: [STDS-802-11-TGBN] TGbn PHY Motion Request

Hi Alfred,

Please add also the followings to the TGbn PHY motion list:

Motion 1: Move to include the following text to the 11bn SFD: (DCN# 11-24/1478r4)

ELR packet detection is done at L-STF, which has same length as legacy with 3dB power boosting

L-LTF also has same length as legacy with same power boosting as L-STF

Results: 49Y, 8N, 14A

Motion 2: Move to include the following text to the 11bn SFD: (DCN# 11-24/1478r4)

U-SIG carries STA-ID in ELR PPDU

Passed without any objection

Motion 3: Move to include the following text to the 11bn SFD: (DCN# 11-24/1478r4)

Define two ELR-Mark symbols for ELR mode classification

ELR-Mark symbols carry a known sequence to receiver
ELR-Mark symbols carry BSS color info in ELR-Mark sequence
No power boosting on ELR-Mark symbols
Two ELR-Mark symbols are both QBPSK modulated on data subcarriers
ELR-Mark symbols use the following tone plan

4 regular pilots as EHT-SIG + 48 data tones

Passed without any objection

Motion 4: Move to include the following text to the 11bn SFD: (DCN# 11-24/1478r4)

11bn defines the following PPDU frame format for ELR

PE TBD

Passed without any objection

Motion 5: Move to include the following text to the 11bn SFD: (DCN# 11-24/1478r4)

ELR PPDU has 3dB boosting applied on both ELR-STF and ELR-LTF

ELR PPDU has ELR-STF duration and sequence same as that of UHR DL SU/MU PPDU

4us using EHT-STF sequence for 20MHz

ELR PPDU defines a fixed/single mode of LTF+GI

11bn supports 2x LTF+1.6us GI only for ELR PPDU
11bn uses two UHR-LTF symbols for ELR PPDU

Note that ELR-STF/ELR-LTF are the short names of UHR-STF/UHR-LTF for ELR PPDU

Passed without any objection

Motion 6: Move to include the following text to the 11bn SFD: (DCN# 11-24/1478r4)

ELR PPDU defines two symbols for ELR-SIG, specifically

ELR PPDU defines separately encoded two symbols for ELR-SIG

Each symbol has separate CRC and tail bits (6 bits)

ELR-SIG has same tone plan and duplication scheme as ELR-data and BCC encoded with MCS0

Passed without any objection

Thanks,

Lin

From: Wook Bong Lee <000020fa465351a2-dmarc-request@xxxxxxxxxxxxxxxxx>
Sent: Tuesday, November 12, 2024 8:40 PM
To: STDS-802-11-TGBN@xxxxxxxxxxxxxxxxx
Subject: Re: [STDS-802-11-TGBN] TGbn PHY Motion Request

WARNING: This email originated from outside of Qualcomm. Please be wary of any links or attachments, and do not enable macros.

Both of them are from (DCN #11-241573r1).

Thank.

Best regards,

Wook Bong Lee

On Nov 12, 2024, at 8:38 PM, Wook Bong Lee <000020fa465351a2-dmarc-request@xxxxxxxxxxxxxxxxx> wrote:

Hi Alfred,

Can you please add the following PHY motions to the motion list?

Do you agree to add following text to the TGbn SFD? (DCN #11-24/1573r1)

Define an enhanced long range (ELR) PPDU in IEEE 802.11bn with the following targets

Downlink and Uplink in 2.4 GHz (within BSS range with 11b beacon)
Uplink only in 5 GHz and 6 GHz bands
Minimum data rate is greater than or equal to 1.5 Mbps

Result: no objection

Do you agree to add the following text to the TGbn SFD?

In ELR PPDU, STA boosts L-STF and L-LTF by 3 dB

For UL, non-AP STA corrects CFO before transmission
Note: Non-AP STA pre-correction CFO requirement for residual CFO is TBD

Result: 51 Y/ 6 N/ 23 Abs

Thank you.

Best regards,

Wook Bong Lee

On Nov 12, 2024, at 7:44 PM, Eunsung Park <esung.park@xxxxxxx> wrote:

Hi Alfred,

Could you please add the following PHY motions to the motion list?

-       M1: Move to add the following text to the TGbn SFD (DCN# 11-24/1097r1)

n  For a DRU transmission, a new 4x UHR-LTF sequence is defined in each distribution bandwidth

u  A 4x UHR-LTF sequence has coefficients on all tones overlapped with DRU tones defined in each distribution bandwidth

n  Result: no objection

-       M2: to add the following text to the TGbn SFD (DCN# 11-24/1097r1)

n  In a PPDU using DRUs, a UHR-LTF sequence corresponding to the distribution bandwidth of the DRUs is used regardless of the PPDU bandwidth

n  Result: no objection

-       M3: Move to add the following text to the TGbn SFD (DCN# 11-24/1471r3)

n  For 80 MHz PPDU where one of the 20 MHz channels is punctured, the following distribution bandwidth mode is allowed for DRU

u  20 MHz + 40 MHz (or 40 MHz + 20 MHz) mode

n  Result: no objection

-       M4: Move to add the following text to the TGbn SFD

n  For 160 MHz and 320 MHz PPDUs, in an 80 MHz frequency subblock where one of the 20 MHz channels is punctured, the following distribution bandwidth mode is allowed for DRU

u  20 MHz + 40 MHz (or 40 MHz + 20 MHz) mode

n  Result: no objection

-       M5: Move to add the following text to the TGbn SFD

n  For 160 MHz and 320 MHz PPDUs, in an 80 MHz frequency subblock where one of the 40 MHz channels is punctured (i.e., either 1100 or 0011 case), the following distribution bandwidth mode is allowed for DRU

u  40 MHz mode

n  Y/N/A: 46/12/16

-       M6: Move to add the following text to the TGbn SFD

n  For a 40 MHz PPDU, the following distribution bandwidth mode is allowed for DRU

u  Only 40 MHz mode

n  Result: no objection

Best regards,

Eunsung
